TDK Corporation VLS3012ET-2R2M-CA
- Mfg. Part Number
- VLS3012ET-2R2M-CA
- Manufacturer
- TDK Corporation
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 2.2UH 1.7A 96 MOHM SMD
- Datasheet Download
- VLS3012ET-2R2M-CA.pdf
Availability of VLS3012ET-2R2M-CA
Available Quantity
7020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.17556
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of VLS3012ET-2R2M-CA, we specialize in TDK Corporation all series electronic components. VLS3012ET-2R2M-CA can be shipped within 24 hours after order. If you have any demands for VLS3012ET-2R2M-CA, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- VLS3012ET-2R2M-CA Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
VLS3012ET-2R2M-CA
| Internal Part Number | EIS-VLS3012ET-2R2M-CA | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | VLS-E-CA Series Automotive Low-Profile Power Inductor | |
| Standard Package | 2,000 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | VLS-E-CA | |
| Packaging | Tape & Reel (TR) | |
| Type | Wirewound | |
| Material - Core | Ferrite | |
| Inductance | 2.2µH | |
| Tolerance | ±20% | |
| Current Rating | 1.7A | |
| Current - Saturation | 1.35A | |
| Shielding | Shielded | |
| DC Resistance (DCR) | 96 mOhm Max | |
| Q @ Freq | - | |
| Frequency - Self Resonant | - | |
| Operating Temperature | -40°C ~ 105°C | |
| Frequency - Test | 1MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | Nonstandard | |
| Size / Dimension | 0.118" L x 0.118" W (3.00mm x 3.00mm) | |
| Height - Seated (Max) | 0.047" (1.20mm) | |
| Supplier Device Package | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | VLS3012ET-2R2M-CA | |
| Related Links | VLS3012E, VLS3012ET-2R2M-CA Datasheet, TDK Corporation Distributor | |
VLS3012ET-2R2M-CA Details Description
