API Delevan WW1008R-10NK
- Mfg. Part Number
- WW1008R-10NK
- Manufacturer
- API Delevan
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 10NH 1A 80 MOHM SMD
- Datasheet Download
- WW1008R-10NK.pdf
Availability of WW1008R-10NK
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.29450
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of WW1008R-10NK, we specialize in API Delevan all series electronic components. WW1008R-10NK can be shipped within 24 hours after order. If you have any demands for WW1008R-10NK, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- WW1008R-10NK Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
WW1008R-10NK
| Internal Part Number | EIS-WW1008R-10NK | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 8,000 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | WW1008R | |
| Packaging | Tape & Reel (TR) | |
| Type | Wirewound | |
| Material - Core | Ceramic | |
| Inductance | 10nH | |
| Tolerance | ±10% | |
| Current Rating | 1A | |
| Current - Saturation | - | |
| Shielding | Unshielded | |
| DC Resistance (DCR) | 80 mOhm Max | |
| Q @ Freq | 50 @ 500MHz | |
| Frequency - Self Resonant | 4.1GHz | |
| Operating Temperature | -40°C ~ 125°C | |
| Frequency - Test | 50MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | Nonstandard | |
| Size / Dimension | 0.115" L x 0.110" W (2.92mm x 2.79mm) | |
| Height - Seated (Max) | 0.080" (2.03mm) | |
| Supplier Device Package | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | WW1008R-10NK | |
| Related Links | WW1008, WW1008R-10NK Datasheet, API Delevan Distributor | |
WW1008R-10NK Details Description
