Digi International XBP24-Z7UIT-005
- Mfg. Part Number
- XBP24-Z7UIT-005
- Manufacturer
- Digi International
- Product Category
- RF Transceiver Modules
- Brief Description
- XBEE PRO SET 50MW U.FL ANTENNA
- Datasheet Download
- XBP24-Z7UIT-005.pdf
Availability of XBP24-Z7UIT-005
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 34.00000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of XBP24-Z7UIT-005, we specialize in Digi International all series electronic components. XBP24-Z7UIT-005 can be shipped within 24 hours after order. If you have any demands for XBP24-Z7UIT-005, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- XBP24-Z7UIT-005 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
XBP24-Z7UIT-005
| Internal Part Number | EIS-XBP24-Z7UIT-005 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | XBee™ Family Chart XBee Migration Guide | |
| Product Training Modules | How to Perform a Range Test Between Two XBee Modules Chat Session via XBee | |
| Video File | XBees Soar into Space on NASA Rocket | |
| RoHS Information | RoHS Declaration of Compliance | |
| Design Resources | Development Tool Selector | |
| Featured Product | Digi International - The World of Xbee | |
| PCN Obsolescence/ EOL | Xbee/PRO ZigBee S2/S2B EOL 19/Nov/2015 | |
| PCN Design/Specification | Release of XCTU 6.2 16/Jun/2015 | |
| Standard Package | 1 | |
| Category | RF/IF and RFID | |
| Family | RF Transceiver Modules | |
| Series | XBee-Pro® | |
| Packaging | Bulk | |
| RF Family/Standard | General ISM/SRD > 1GHZ | |
| Protocol | - | |
| Modulation | DSSS | |
| Frequency | 2.4GHz | |
| Data Rate | 250kbps | |
| Power - Output | 17dBm | |
| Sensitivity | -102dBm | |
| Serial Interfaces | UART | |
| Antenna Type | Not Included, U.FL | |
| Memory Size | - | |
| Voltage - Supply | 3 V ~ 3.4 V | |
| Current - Receiving | 45mA | |
| Current - Transmitting | 295mA | |
| Mounting Type | Through Hole | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | Module | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | XBP24-Z7UIT-005 | |
| Related Links | XBP24-Z, XBP24-Z7UIT-005 Datasheet, Digi International Distributor | |
