Mill-Max 0384-0-67-80-23-27-10-0
- Mfg. Part Number
- 0384-0-67-80-23-27-10-0
- Manufacturer
- Mill-Max
- Product Category
- Terminals - PC Pin Receptacles, Socket Connectors
- Brief Description
- CONN OFP PIN RCPT .045/.065" DIA
- Datasheet Download
- 0384-0-67-80-23-27-10-0.pdf
Availability of 0384-0-67-80-23-27-10-0
Available Quantity
15020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.48156
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 0384-0-67-80-23-27-10-0, we specialize in Mill-Max all series electronic components. 0384-0-67-80-23-27-10-0 can be shipped within 24 hours after order. If you have any demands for 0384-0-67-80-23-27-10-0, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 0384-0-67-80-23-27-10-0 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
0384-0-67-80-23-27-10-0
| Internal Part Number | EIS-0384-0-67-80-23-27-10-0 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Pin Receptacles | |
| Featured Product | OFP Receptacles and Sockets | |
| Standard Package | 2,000 | |
| Category | Connectors, Interconnects | |
| Family | Terminals - PC Pin Receptacles, Socket Connectors | |
| Series | 0384 | |
| Packaging | Tape & Reel (TR) | |
| Tail Type | No Tail | |
| Termination | Solder | |
| Length - Overall | 0.140" (3.56mm) | |
| Accepts Pin Diameter | 0.045" ~ 0.065" (1.14mm ~ 1.65mm) | |
| Mounting Hole Diameter | 0.105" (2.67mm) | |
| Pin Hole Diameter | 0.088" (2.24mm) | |
| Flange Diameter | 0.122" (3.10mm) | |
| Tail Diameter | - | |
| Socket Depth | 0.140" (3.56mm) | |
| Contact Material | Beryllium Copper | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 30µin (0.76µm) | |
| Features | Knockout Bottom (Organic Fiber Plug®) | |
| Operating Temperature | -55°C ~ 125°C | |
| Board Thickness | - | |
| Insertion Force | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 0384-0-67-80-23-27-10-0 | |
| Related Links | 0384-0-67-8, 0384-0-67-80-23-27-10-0 Datasheet, Mill-Max Distributor | |
