Cinch Connectivity Solutions 1840242-1
- Mfg. Part Number
- 1840242-1
- Manufacturer
- Cinch Connectivity Solutions
- Product Category
- Modular Connectors - Jacks With Magnetics
- Brief Description
- CONN MAGJACK 4PORT GIGABIT
- Datasheet Download
- 1840242-1.pdf
Availability of 1840242-1
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 13.03750
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 1840242-1, we specialize in Cinch Connectivity Solutions all series electronic components. 1840242-1 can be shipped within 24 hours after order. If you have any demands for 1840242-1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 1840242-1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
1840242-1
| Internal Part Number | EIS-1840242-1 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 60 | |
| Category | Connectors, Interconnects | |
| Family | Modular Connectors - Jacks With Magnetics | |
| Series | - | |
| Packaging | Bulk | |
| Connector Type | Jack | |
| Number of Ports | 4 | |
| Number of Rows | 2 | |
| Applications | 10/100/1000 Base-T | |
| Mounting Type | Board Edge, Through Hole | |
| Orientation | 90° Angle (Right) | |
| Termination | Solder | |
| Height Above Board | - | |
| LED Color | Green, Yellow - Green, Yellow | |
| Number of Cores per Jack | - | |
| Shielding | Shielded, EMI Finger | |
| Features | Board Lock | |
| Tab Direction | Up and Down | |
| Contact Material | Phosphor Bronze | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 50µin (1.27µm) | |
| Shield Material | Brass | |
| Housing Material | Thermoplastic | |
| Operating Temperature | 0°C ~ 70°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 1840242-1 | |
| Related Links | 1840, 1840242-1 Datasheet, Cinch Connectivity Solutions Distributor | |
1840242-1 Details Description
