Silicon Labs 504MBA-ABAG
- Mfg. Part Number
- 504MBA-ABAG
- Manufacturer
- Silicon Labs
- Product Category
- Programmable Oscillators
- Brief Description
- OSC PROG 2.5NS 30PPM 3.2X5MM
- Datasheet Download
- 504MBA-ABAG.pdf
Availability of 504MBA-ABAG
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.99263
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 504MBA-ABAG, we specialize in Silicon Labs all series electronic components. 504MBA-ABAG can be shipped within 24 hours after order. If you have any demands for 504MBA-ABAG, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 504MBA-ABAG Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
504MBA-ABAG
| Internal Part Number | EIS-504MBA-ABAG | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | CMEMS Technology and Si501/2/3/4 CMEMS Oscillators Clock Tree Timing Solutions | |
| Featured Product | Si50x CMEMS® Programmable Oscillators Silicon Labs - Solutions For The Internet Of Things | |
| Standard Package | 1 | |
| Category | Crystals and Oscillators | |
| Family | Programmable Oscillators | |
| Series | CMEMS® Si504 | |
| Packaging | Tray | |
| Type | Programmed by Digi-Key (Enter your frequency in Web Order Notes) | |
| Available Frequency Range | 32kHz ~ 80MHz | |
| Function | Standby | |
| Output | LVCMOS | |
| Voltage - Supply | 1.8 V ~ 3.3 V | |
| Frequency Stability | ±30ppm | |
| Operating Temperature | -40°C ~ 85°C | |
| Spread Spectrum Bandwidth | - | |
| Current - Supply (Max) | 8.9mA | |
| Mounting Type | Surface Mount | |
| Package / Case | 4-SMD, No Lead (DFN, LCC) | |
| Height | 0.035" (0.90mm) | |
| Size / Dimension | 0.157" L x 0.126" W (4.00mm x 3.20mm) | |
| Current - Supply (Disable) (Max) | 1µA | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 504MBA-ABAG | |
| Related Links | 504MB, 504MBA-ABAG Datasheet, Silicon Labs Distributor | |
