C&K Components 7101J3Z3BE3
- Mfg. Part Number
- 7101J3Z3BE3
- Manufacturer
- C&K Components
- Product Category
- Rocker Switches
- Brief Description
- SWITCH ROCKER SPDT 0.4VA 20V
- Datasheet Download
- 7101J3Z3BE3.pdf
Availability of 7101J3Z3BE3
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 7.18880
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 7101J3Z3BE3, we specialize in C&K Components all series electronic components. 7101J3Z3BE3 can be shipped within 24 hours after order. If you have any demands for 7101J3Z3BE3, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 7101J3Z3BE3 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
7101J3Z3BE3
| Internal Part Number | EIS-7101J3Z3BE3 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Rocker Switches | |
| Series | 7000 | |
| Packaging | Bulk | |
| Circuit | SPDT | |
| Switch Function | On-On | |
| Current Rating | 0.4VA (AC/DC) | |
| Voltage Rating - AC | 20V | |
| Voltage Rating - DC | 20V | |
| Actuator Type | Concave (Standard V) | |
| Color - Actuator/Cap | Red | |
| Actuator Marking | No Marking | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Panel Mount, Flange | |
| Termination Style | Quick Connect - 0.062" (1.5mm) | |
| Ingress Protection | - | |
| Features | Epoxy Sealed Terminals | |
| Panel Cutout Dimensions | Rectangular - 27.81mm x 16.46mm | |
| Operating Temperature | -30°C ~ 85°C | |
| Mechanical Life | - | |
| Electrical Life | 100,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 7101J3Z3BE3 | |
| Related Links | 7101J, 7101J3Z3BE3 Datasheet, C&K Components Distributor | |
7101J3Z3BE3 Details Description
