Skyworks Solutions Inc. AAT4614IJS-2-T1
- Mfg. Part Number
- AAT4614IJS-2-T1
- Manufacturer
- Skyworks Solutions Inc.
- Product Category
- PMIC - Power Distribution Switches, Load Drivers
- Brief Description
- LOAD SWITCH FAULT FLAG SC70JW-8
- Datasheet Download
- AAT4614IJS-2-T1.pdf
Availability of AAT4614IJS-2-T1
Available Quantity
8020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.27500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AAT4614IJS-2-T1, we specialize in Skyworks Solutions Inc. all series electronic components. AAT4614IJS-2-T1 can be shipped within 24 hours after order. If you have any demands for AAT4614IJS-2-T1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AAT4614IJS-2-T1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AAT4614IJS-2-T1
| Internal Part Number | EIS-AAT4614IJS-2-T1 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | Multiple Devices 12/Jan/2015 | |
| Standard Package | 3,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Power Distribution Switches, Load Drivers | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Switch Type | General Purpose | |
| Number of Outputs | 1 | |
| Ratio - Input:Output | 1:1 | |
| Output Configuration | High Side | |
| Output Type | P-Channel | |
| Interface | On/Off | |
| Voltage - Load | 2.4 V ~ 5.5 V | |
| Voltage - Supply (Vcc/Vdd) | Not Required | |
| Current - Output (Max) | 2A | |
| Rds On (Typ) | 160 mOhm | |
| Input Type | Non-Inverting | |
| Features | Status Flag | |
| Fault Protection | Current Limiting (Adjustable), Over Temperature, Reverse Current, UVLO | |
| Operating Temperature | -40°C ~ 85°C (TA) | |
| Package / Case | 8-TFSOJ (0.069", 1.75mm Width) | |
| Supplier Device Package | 8-SC70JW | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AAT4614IJS-2-T1 | |
| Related Links | AAT4614, AAT4614IJS-2-T1 Datasheet, Skyworks Solutions Inc. Distributor | |
AAT4614IJS-2-T1 Details Description
