Sullins Connector Solutions ABM22DSEN
- Mfg. Part Number
- ABM22DSEN
- Manufacturer
- Sullins Connector Solutions
- Product Category
- Card Edge Connectors - Edgeboard Connectors
- Brief Description
- CONN EDGECARD 44POS .156 EYELET
- Datasheet Download
- ABM22DSEN.pdf
Availability of ABM22DSEN
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 13.60800
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ABM22DSEN, we specialize in Sullins Connector Solutions all series electronic components. ABM22DSEN can be shipped within 24 hours after order. If you have any demands for ABM22DSEN, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ABM22DSEN Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ABM22DSEN
| Internal Part Number | EIS-ABM22DSEN | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Card Edge Connectors - Edgeboard Connectors | |
| Series | - | |
| Packaging | Tray | |
| Card Type | Non Specified - Dual Edge | |
| Gender | Female | |
| Number of Positions/Bay/Row | 22 | |
| Number of Positions | 44 | |
| Card Thickness | 0.062" (1.57mm) | |
| Number of Rows | 2 | |
| Pitch | 0.156" (3.96mm) | |
| Features | - | |
| Mounting Type | Free Hanging (In-Line) | |
| Termination | Solder Eyelet(s) | |
| Contact Material | Beryllium Copper | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 10µin (0.25µm) | |
| Contact Type | Full Bellows | |
| Color | Green | |
| Flange Feature | - | |
| Operating Temperature | -65°C ~ 150°C | |
| Material - Insulation | Polyphenylene Sulfide (PPS) | |
| Read Out | Dual | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ABM22DSEN | |
| Related Links | ABM2, ABM22DSEN Datasheet, Sullins Connector Solutions Distributor | |
ABM22DSEN Details Description
