Texas Instruments ADC1175CIMTCX/NOPB
- Mfg. Part Number
- ADC1175CIMTCX/NOPB
- Manufacturer
- Texas Instruments
- Product Category
- Data Acquisition - Analog to Digital Converters (ADC)
- Brief Description
- IC ADC 8BIT 20MHZ 85MW 24-TSSOP
- Datasheet Download
- ADC1175CIMTCX/NOPB.pdf
Availability of ADC1175CIMTCX/NOPB
Available Quantity
15020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.25000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ADC1175CIMTCX/NOPB, we specialize in Texas Instruments all series electronic components. ADC1175CIMTCX/NOPB can be shipped within 24 hours after order. If you have any demands for ADC1175CIMTCX/NOPB, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ADC1175CIMTCX/NOPB Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ADC1175CIMTCX/NOPB
| Internal Part Number | EIS-ADC1175CIMTCX/NOPB | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 2,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | Data Acquisition - Analog to Digital Converters (ADC) | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Number of Bits | 8 | |
| Sampling Rate (Per Second) | 20M | |
| Number of Inputs | 1 | |
| Input Type | Single Ended | |
| Data Interface | Parallel | |
| Configuration | S/H-ADC | |
| Ratio - S/H:ADC | 1:1 | |
| Number of A/D Converters | 1 | |
| Architecture | Two-Step | |
| Reference Type | External, Internal | |
| Voltage - Supply, Analog | 5V | |
| Voltage - Supply, Digital | 5V | |
| Features | - | |
| Operating Temperature | -20°C ~ 75°C | |
| Package / Case | 24-TSSOP (0.173", 4.40mm Width) | |
| Supplier Device Package | 24-TSSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ADC1175CIMTCX/NOPB | |
| Related Links | ADC1175CI, ADC1175CIMTCX/NOPB Datasheet, Texas Instruments Distributor | |
ADC1175CIMTCX/NOPB Details Description
