Analog ADV7282WBCPZ-RL
- Mfg. Part Number
- ADV7282WBCPZ-RL
- Manufacturer
- Analog
- Product Category
- Interface - CODECs
- Brief Description
- IC VIDEO DECODER 10BIT 32LFCSP
- Datasheet Download
- ADV7282WBCPZ-RL.pdf
Availability of ADV7282WBCPZ-RL
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 8.04000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ADV7282WBCPZ-RL, we specialize in Analog all series electronic components. ADV7282WBCPZ-RL can be shipped within 24 hours after order. If you have any demands for ADV7282WBCPZ-RL, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ADV7282WBCPZ-RL Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ADV7282WBCPZ-RL
| Internal Part Number | EIS-ADV7282WBCPZ-RL | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | Chipset Solution for Automotive Head Units and Audio Amps | |
| Standard Package | 5,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | Interface - CODECs | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Type | Video | |
| Data Interface | I²C, Serial | |
| Resolution (Bits) | 10 b | |
| Number of ADCs / DACs | 1 / 0 | |
| Sigma Delta | No | |
| S/N Ratio, ADCs / DACs (db) Typ | - | |
| Dynamic Range, ADCs / DACs (db) Typ | - | |
| Voltage - Supply, Analog | 1.71 V ~ 1.89 V | |
| Voltage - Supply, Digital | 1.71 V ~ 1.95 V | |
| Operating Temperature | -40°C ~ 105°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 32-WFQFN Exposed Pad, CSP | |
| Supplier Device Package | 32-LFCSP-WQ (5x5) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ADV7282WBCPZ-RL | |
| Related Links | ADV7282, ADV7282WBCPZ-RL Datasheet, Analog Distributor | |
ADV7282WBCPZ-RL Details Description
