Alpha & Omega Semiconductor Inc. AOT15S60L
- Mfg. Part Number
- AOT15S60L
- Manufacturer
- Alpha & Omega Semiconductor Inc.
- Product Category
- FETs - Single
- Brief Description
- MOSFET N-CH 600V 15A TO220
- Datasheet Download
- AOT15S60L.pdf
Availability of AOT15S60L
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.08750
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AOT15S60L, we specialize in Alpha & Omega Semiconductor Inc. all series electronic components. AOT15S60L can be shipped within 24 hours after order. If you have any demands for AOT15S60L, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AOT15S60L Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AOT15S60L
| Internal Part Number | EIS-AOT15S60L | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | AOS Green Policy | |
| Standard Package | 1,000 | |
| Category | Discrete Semiconductor Products | |
| Family | FETs - Single | |
| Series | aMOS™ | |
| Packaging | Tube | |
| FET Type | MOSFET N-Channel, Metal Oxide | |
| FET Feature | Standard | |
| Drain to Source Voltage (Vdss) | 600V | |
| Current - Continuous Drain (Id) @ 25°C | 15A (Tc) | |
| Rds On (Max) @ Id, Vgs | 290 mOhm @ 7.5A, 10V | |
| Vgs(th) (Max) @ Id | 3.8V @ 250µA | |
| Gate Charge (Qg) @ Vgs | 15.6nC @ 10V | |
| Input Capacitance (Ciss) @ Vds | 372pF @ 100V | |
| Power - Max | 208W | |
| Mounting Type | Through Hole | |
| Package / Case | TO-220-3 | |
| Supplier Device Package | TO-220 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AOT15S60L | |
| Related Links | AOT1, AOT15S60L Datasheet, Alpha & Omega Semiconductor Inc. Distributor | |
AOT15S60L Details Description
