EPCOS (TDK) B82472P6224M
- Mfg. Part Number
- B82472P6224M
- Manufacturer
- EPCOS (TDK)
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 220UH 430MA 880 MOHM
- Datasheet Download
- B82472P6224M.pdf
Availability of B82472P6224M
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.83344
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of B82472P6224M, we specialize in EPCOS (TDK) all series electronic components. B82472P6224M can be shipped within 24 hours after order. If you have any demands for B82472P6224M, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- B82472P6224M Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
B82472P6224M
| Internal Part Number | EIS-B82472P6224M | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 1,000 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | Automotive, AEC-Q200, B82472P6 | |
| Packaging | Tape & Reel (TR) | |
| Type | Wirewound | |
| Material - Core | Ferrite | |
| Inductance | 220µH | |
| Tolerance | ±20% | |
| Current Rating | 430mA | |
| Current - Saturation | 360mA | |
| Shielding | Shielded | |
| DC Resistance (DCR) | 880 mOhm Max | |
| Q @ Freq | - | |
| Frequency - Self Resonant | - | |
| Operating Temperature | - | |
| Frequency - Test | 100kHz | |
| Mounting Type | Surface Mount | |
| Package / Case | Nonstandard | |
| Size / Dimension | 0.287" L x 0.287" W (7.30mm x 7.30mm) | |
| Height - Seated (Max) | 0.177" (4.50mm) | |
| Supplier Device Package | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | B82472P6224M | |
| Related Links | B82472, B82472P6224M Datasheet, EPCOS (TDK) Distributor | |
B82472P6224M Details Description
