Infineon Technologies BSC0911NDATMA1
- Mfg. Part Number
- BSC0911NDATMA1
- Manufacturer
- Infineon Technologies
- Product Category
- FETs - Arrays
- Brief Description
- MOSFET 2N-CH 25V 18A/30A TISON-8
- Datasheet Download
- BSC0911NDATMA1.pdf
Availability of BSC0911NDATMA1
Available Quantity
9620 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.03346
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of BSC0911NDATMA1, we specialize in Infineon Technologies all series electronic components. BSC0911NDATMA1 can be shipped within 24 hours after order. If you have any demands for BSC0911NDATMA1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- BSC0911NDATMA1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
BSC0911NDATMA1
| Internal Part Number | EIS-BSC0911NDATMA1 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Discrete Semiconductor Products | |
| Family | FETs - Arrays | |
| Series | OptiMOS™ | |
| Packaging | Cut Tape (CT) | |
| FET Type | 2 N-Channel (Dual) Asymmetrical | |
| FET Feature | Logic Level Gate, 4.5V Drive | |
| Drain to Source Voltage (Vdss) | 25V | |
| Current - Continuous Drain (Id) @ 25°C | 18A, 30A | |
| Rds On (Max) @ Id, Vgs | 3.2 mOhm @ 20A, 10V | |
| Vgs(th) (Max) @ Id | 2V @ 250µA | |
| Gate Charge (Qg) @ Vgs | 12nC @ 4.5V | |
| Input Capacitance (Ciss) @ Vds | 1600pF @ 12V | |
| Power - Max | 1W | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-PowerTDFN | |
| Supplier Device Package | PG-TISON-8 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | BSC0911NDATMA1 | |
| Related Links | BSC0911, BSC0911NDATMA1 Datasheet, Infineon Technologies Distributor | |
BSC0911NDATMA1 Details Description
