Taiyo Yuden CB2016T1R0M
- Mfg. Part Number
- CB2016T1R0M
- Manufacturer
- Taiyo Yuden
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 1UH 1.1A 117 MOHM SMD
- Datasheet Download
- CB2016T1R0M.pdf
Availability of CB2016T1R0M
Available Quantity
7020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.06900
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CB2016T1R0M, we specialize in Taiyo Yuden all series electronic components. CB2016T1R0M can be shipped within 24 hours after order. If you have any demands for CB2016T1R0M, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CB2016T1R0M Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CB2016T1R0M
| Internal Part Number | EIS-CB2016T1R0M | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 2,000 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | CB | |
| Packaging | Tape & Reel (TR) | |
| Type | Wirewound | |
| Material - Core | - | |
| Inductance | 1µH | |
| Tolerance | ±20% | |
| Current Rating | 1.1A | |
| Current - Saturation | 600mA | |
| Shielding | Unshielded | |
| DC Resistance (DCR) | 117 mOhm Max | |
| Q @ Freq | - | |
| Frequency - Self Resonant | 100MHz | |
| Operating Temperature | -40°C ~ 105°C | |
| Frequency - Test | 7.96MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | 0806 (2016 Metric) | |
| Size / Dimension | 0.079" L x 0.063" W (2.00mm x 1.60mm) | |
| Height - Seated (Max) | 0.071" (1.80mm) | |
| Supplier Device Package | 0806 (2016 Metric) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CB2016T1R0M | |
| Related Links | CB201, CB2016T1R0M Datasheet, Taiyo Yuden Distributor | |
CB2016T1R0M Details Description
