Sumida Corporation CDRH4D16F/LDNP-4R7NC
- Mfg. Part Number
- CDRH4D16F/LDNP-4R7NC
- Manufacturer
- Sumida Corporation
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 4.7UH 2.5A 42.4 MOHM
- Datasheet Download
- CDRH4D16F/LDNP-4R7NC.pdf
Availability of CDRH4D16F/LDNP-4R7NC
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.35700
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CDRH4D16F/LDNP-4R7NC, we specialize in Sumida Corporation all series electronic components. CDRH4D16F/LDNP-4R7NC can be shipped within 24 hours after order. If you have any demands for CDRH4D16F/LDNP-4R7NC, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CDRH4D16F/LDNP-4R7NC Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CDRH4D16F/LDNP-4R7NC
| Internal Part Number | EIS-CDRH4D16F/LDNP-4R7NC | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1,000 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | CDRH4D16F/LD | |
| Packaging | Tape & Reel (TR) | |
| Type | - | |
| Material - Core | - | |
| Inductance | 4.7µH | |
| Tolerance | ±25% | |
| Current Rating | 2.5A | |
| Current - Saturation | 600mA | |
| Shielding | Unshielded | |
| DC Resistance (DCR) | 42.4 mOhm Max | |
| Q @ Freq | - | |
| Frequency - Self Resonant | - | |
| Operating Temperature | - | |
| Frequency - Test | 100kHz | |
| Mounting Type | Surface Mount | |
| Package / Case | Nonstandard | |
| Size / Dimension | 0.157" L x 0.157" W (4.00mm x 4.00mm) | |
| Height - Seated (Max) | 0.071" (1.80mm) | |
| Supplier Device Package | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CDRH4D16F/LDNP-4R7NC | |
| Related Links | CDRH4D16F/, CDRH4D16F/LDNP-4R7NC Datasheet, Sumida Corporation Distributor | |
CDRH4D16F/LDNP-4R7NC Details Description
