TDK Corporation CGJ3E2C0G1H1R5C080AA
.jpg)
- Mfg. Part Number
- CGJ3E2C0G1H1R5C080AA
- Manufacturer
- TDK Corporation
- Product Category
- Ceramic Capacitors
- Brief Description
- CAP CER 1.5PF 50V C0G 0603
- Datasheet Download
- CGJ3E2C0G1H1R5C080AA.pdf
Availability of CGJ3E2C0G1H1R5C080AA
Available Quantity
9020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.04055
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CGJ3E2C0G1H1R5C080AA, we specialize in TDK Corporation all series electronic components. CGJ3E2C0G1H1R5C080AA can be shipped within 24 hours after order. If you have any demands for CGJ3E2C0G1H1R5C080AA, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CGJ3E2C0G1H1R5C080AA Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CGJ3E2C0G1H1R5C080AA
| Internal Part Number | EIS-CGJ3E2C0G1H1R5C080AA | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | CGJ Series High Reliability SEAT, CCV, and TVCL Design Tools Guide to Replacing an Electrolytic Capacitor with an MLCC | |
| Video File | High Capacitance Capacitor Measurement Tutorial | |
| RoHS Information | RoHS Certificate-MLCC | |
| Featured Product | CGJ Series | |
| PCN Part Number | MLCC Part Number Change 30/Nov/2012 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 4,000 | |
| Category | Capacitors | |
| Family | Ceramic Capacitors | |
| Series | CGJ | |
| Packaging | Tape & Reel (TR) | |
| Capacitance | 1.5pF | |
| Tolerance | ±0.25pF | |
| Voltage - Rated | 50V | |
| Temperature Coefficient | C0G, NP0 | |
| Mounting Type | Surface Mount, MLCC | |
| Operating Temperature | -55°C ~ 125°C | |
| Applications | High Reliability | |
| Ratings | COTS | |
| Package / Case | 0603 (1608 Metric) | |
| Size / Dimension | 0.063" L x 0.031" W (1.60mm x 0.80mm) | |
| Height - Seated (Max) | - | |
| Thickness (Max) | 0.031" (0.80mm) | |
| Lead Spacing | - | |
| Features | - | |
| Lead Style | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CGJ3E2C0G1H1R5C080AA | |
| Related Links | CGJ3E2C0G1, CGJ3E2C0G1H1R5C080AA Datasheet, TDK Corporation Distributor | |
