ON Semiconductor CS7054YDWR16
.jpg)
- Mfg. Part Number
- CS7054YDWR16
- Manufacturer
- ON Semiconductor
- Product Category
- PMIC - Motor Drivers, Controllers
- Brief Description
- IC MOTOR CONTROLLER PAR 16SOIC
- Datasheet Download
- CS7054YDWR16.pdf
Availability of CS7054YDWR16
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CS7054YDWR16, we specialize in ON Semiconductor all series electronic components. CS7054YDWR16 can be shipped within 24 hours after order. If you have any demands for CS7054YDWR16, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CS7054YDWR16 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CS7054YDWR16
| Internal Part Number | EIS-CS7054YDWR16 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | Multiple Devices 30/Dec/2003 | |
| Standard Package | 1,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Motor Drivers, Controllers | |
| Series | - | |
| Motor Type - Stepper | - | |
| Motor Type - AC, DC | Brushed DC | |
| Function | Controller - Commutation, Direction Management | |
| Output Configuration | Pre-Driver - Low Side | |
| Interface | Parallel | |
| Technology | Power MOSFET | |
| Step Resolution | - | |
| Applications | General Purpose | |
| Current - Output | - | |
| Voltage - Supply | 8 V ~ 16 V | |
| Voltage - Load | - | |
| Operating Temperature | -40°C ~ 125°C (TA) | |
| Mounting Type | Surface Mount | |
| Package / Case | 16-SOIC (0.295", 7.50mm Width) | |
| Supplier Device Package | 16-SOIC W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CS7054YDWR16 | |
| Related Links | CS7054, CS7054YDWR16 Datasheet, ON Semiconductor Distributor | |
