Fairchild Semiconductor DM74LS154N
- Mfg. Part Number
- DM74LS154N
- Manufacturer
- Fairchild Semiconductor
- Product Category
- Logic - Signal Switches, Multiplexers, Decoders
- Brief Description
- IC DECODER/DEMUX 4-16LINE 24-DIP
- Datasheet Download
- DM74LS154N.pdf
Availability of DM74LS154N
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DM74LS154N, we specialize in Fairchild Semiconductor all series electronic components. DM74LS154N can be shipped within 24 hours after order. If you have any demands for DM74LS154N, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DM74LS154N Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DM74LS154N
| Internal Part Number | EIS-DM74LS154N | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 15 | |
| Category | Integrated Circuits (ICs) | |
| Family | Logic - Signal Switches, Multiplexers, Decoders | |
| Series | 74LS | |
| Packaging | Tube | |
| Type | Decoder/Demultiplexer | |
| Circuit | 1 x 4:16 | |
| Independent Circuits | 1 | |
| Current - Output High, Low | 400µA, 8mA | |
| Voltage Supply Source | Single Supply | |
| Voltage - Supply | 4.75 V ~ 5.25 V | |
| Operating Temperature | 0°C ~ 70°C | |
| Mounting Type | Through Hole | |
| Package / Case | 24-DIP (0.600", 15.24mm) | |
| Supplier Device Package | 24-PDIP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DM74LS154N | |
| Related Links | DM74L, DM74LS154N Datasheet, Fairchild Semiconductor Distributor | |
DM74LS154N Details Description
