Fairchild Semiconductor FDMS8018
- Mfg. Part Number
- FDMS8018
- Manufacturer
- Fairchild Semiconductor
- Product Category
- FETs - Single
- Brief Description
- MOSFET N-CH 30V 30A 8PQFN
- Datasheet Download
- FDMS8018.pdf
Availability of FDMS8018
Available Quantity
20020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.60000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of FDMS8018, we specialize in Fairchild Semiconductor all series electronic components. FDMS8018 can be shipped within 24 hours after order. If you have any demands for FDMS8018, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- FDMS8018 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
FDMS8018
| Internal Part Number | EIS-FDMS8018 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | Cloud Systems Computing Mid- and Low-Voltage MOSFETs | |
| PCN Assembly/Origin | Wafer 6/8 Inch Addition 16/Jun/2014 | |
| Standard Package | 3,000 | |
| Category | Discrete Semiconductor Products | |
| Family | FETs - Single | |
| Series | PowerTrench® | |
| Packaging | Tape & Reel (TR) | |
| FET Type | MOSFET N-Channel, Metal Oxide | |
| FET Feature | Standard | |
| Drain to Source Voltage (Vdss) | 30V | |
| Current - Continuous Drain (Id) @ 25°C | 30A (Ta), 120A (Tc) | |
| Rds On (Max) @ Id, Vgs | 1.8 mOhm @ 30A, 10V | |
| Vgs(th) (Max) @ Id | 3V @ 250µA | |
| Gate Charge (Qg) @ Vgs | 61nC @ 10V | |
| Input Capacitance (Ciss) @ Vds | 5235pF @ 15V | |
| Power - Max | 2.5W | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-TDFN Exposed Pad | |
| Supplier Device Package | 8-PQFN (5x6), Power56 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | FDMS8018 | |
| Related Links | FDMS, FDMS8018 Datasheet, Fairchild Semiconductor Distributor | |
FDMS8018 Details Description
