Hirose Electric Co Ltd FH35C-41S-0.3SHW(50)
.jpg)
- Mfg. Part Number
- FH35C-41S-0.3SHW(50)
- Manufacturer
- Hirose Electric Co Ltd
- Product Category
- FFC, FPC (Flat Flexible) Connectors
- Brief Description
- CONN FPC 41POS 0.30MM R/A
- Datasheet Download
- FH35C-41S-0.3SHW(50).pdf
Availability of FH35C-41S-0.3SHW(50)
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.30340
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of FH35C-41S-0.3SHW(50), we specialize in Hirose Electric Co Ltd all series electronic components. FH35C-41S-0.3SHW(50) can be shipped within 24 hours after order. If you have any demands for FH35C-41S-0.3SHW(50), Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- FH35C-41S-0.3SHW(50) Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
FH35C-41S-0.3SHW(50)
| Internal Part Number | EIS-FH35C-41S-0.3SHW(50) | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Video File | Tablet PC Connectors - Hirose | |
| Standard Package | 5,000 | |
| Category | Connectors, Interconnects | |
| Family | FFC, FPC (Flat Flexible) Connectors | |
| Series | FH35C | |
| Packaging | Tape & Reel (TR) | |
| Flat Flex Type | FPC | |
| Mounting Type | Surface Mount, Right Angle | |
| Connector/Contact Type | Contacts, Top and Bottom | |
| Number of Positions | 41 | |
| Pitch | 0.012" (0.30mm) | |
| Termination | Solder | |
| FFC, FCB Thickness | 0.20mm | |
| Height Above Board | 0.036" (0.90mm) | |
| Locking Feature | Flip Lock, Backlock | |
| Cable End Type | Tapered | |
| Contact Material | Phosphor Bronze | |
| Contact Finish | Gold | |
| Housing Material | Liquid Crystal Polymer (LCP) | |
| Actuator Material | Polyamide (PA), Nylon | |
| Features | - | |
| Voltage Rating | 30V | |
| Operating Temperature | -55°C ~ 85°C | |
| Material Flammability Rating | UL94 V-0 | |
| Current Rating | 0.2A | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | FH35C-41S-0.3SHW(50) | |
| Related Links | FH35C-41S-, FH35C-41S-0.3SHW(50) Datasheet, Hirose Electric Co Ltd Distributor | |
