Schaffner EMC Inc. FN2020B-3-06
- Mfg. Part Number
- FN2020B-3-06
- Manufacturer
- Schaffner EMC Inc.
- Product Category
- Power Line Filter Modules
- Brief Description
- FILTER 1-PHASE GENERAL EMI 3A
- Datasheet Download
- FN2020B-3-06.pdf
Availability of FN2020B-3-06
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 15.09800
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of FN2020B-3-06, we specialize in Schaffner EMC Inc. all series electronic components. FN2020B-3-06 can be shipped within 24 hours after order. If you have any demands for FN2020B-3-06, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- FN2020B-3-06 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
FN2020B-3-06
| Internal Part Number | EIS-FN2020B-3-06 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 20 | |
| Category | Filters | |
| Family | Power Line Filter Modules | |
| Series | FN 2020 | |
| Filter Type | Single Phase | |
| Configuration | Single Stage | |
| Voltage - Rated DC | - | |
| Voltage - Rated AC | 250V | |
| Current | 3A | |
| Frequency - Operating | 50 ~ 60Hz | |
| Mounting Type | Chassis Mount | |
| Termination Style | Quick Connect | |
| Applications | Medical | |
| Approvals | CSA, ENEC, UL | |
| Operating Temperature | -25°C ~ 100°C | |
| Voltage - Rated AC (Phase to Ground/Neutral) | - | |
| Voltage - Rated AC (Phase to Phase) | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | FN2020B-3-06 | |
| Related Links | FN2020, FN2020B-3-06 Datasheet, Schaffner EMC Inc. Distributor | |
FN2020B-3-06 Details Description
