XP Power ISE0505A
.jpg)
- Mfg. Part Number
- ISE0505A
- Manufacturer
- XP Power
- Product Category
- DC DC Converters
- Brief Description
- DC/DC CONV 1W SMD DUAL OUT
- Datasheet Download
- ISE0505A.pdf
Availability of ISE0505A
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.99533
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ISE0505A, we specialize in XP Power all series electronic components. ISE0505A can be shipped within 24 hours after order. If you have any demands for ISE0505A, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ISE0505A Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ISE0505A
| Internal Part Number | EIS-ISE0505A | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 15 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | ISE | |
| Packaging | Tube | |
| Type | Isolated Module | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 4.5V | |
| Voltage - Input (Max) | 5.5V | |
| Voltage - Output 1 | 5V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 200mA | |
| Power (Watts) - Manufacture Series | 1W | |
| Voltage - Isolation | 1.5kV (1500V) | |
| Features | SCP | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-SMD Module (5 Leads), Gull Wing | |
| Size / Dimension | 0.50" L x 0.33" W x 0.28" H (12.7mm x 8.3mm x 7.0mm) | |
| Operating Temperature | -40°C ~ 105°C | |
| Efficiency | 80% | |
| Power (Watts) - Max | 1W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ISE0505A | |
| Related Links | ISE0, ISE0505A Datasheet, XP Power Distributor | |
ISE0505A Details Description
