NKK Switches KB16KKW01-6B-JB
- Mfg. Part Number
- KB16KKW01-6B-JB
- Manufacturer
- NKK Switches
- Product Category
- Pushbutton Switches
- Brief Description
- SWITCH PUSHBUTTON SPDT 1A 125V
- Datasheet Download
- KB16KKW01-6B-JB.pdf
Availability of KB16KKW01-6B-JB
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 16.78000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of KB16KKW01-6B-JB, we specialize in NKK Switches all series electronic components. KB16KKW01-6B-JB can be shipped within 24 hours after order. If you have any demands for KB16KKW01-6B-JB, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- KB16KKW01-6B-JB Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
KB16KKW01-6B-JB
| Internal Part Number | EIS-KB16KKW01-6B-JB | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | Series, Cert of Compliance | |
| Featured Product | Pushbutton Switches | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Pushbutton Switches | |
| Series | KB | |
| Packaging | Bulk | |
| Type | Standard, Illuminated | |
| Circuit | SPDT | |
| Switch Function | On-On | |
| Current Rating | 1A (AC/DC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 30V | |
| Actuator Type | Square, Button | |
| Color - Actuator/Cap | Clear (White Filter/Diffuser) | |
| Illumination Type, Color | LED, White | |
| Illumination Voltage (Nominal) | 3.6 VDC | |
| Mounting Type | Panel Mount, Snap-In | |
| Termination Style | Solder Lug | |
| Ingress Protection | - | |
| Features | - | |
| Panel Cutout Dimensions | Circular - 12.30mm Dia | |
| Operating Temperature | -25°C ~ 50°C | |
| Mechanical Life | 100,000 Cycles | |
| Electrical Life | 50,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | KB16KKW01-6B-JB | |
| Related Links | KB16KKW, KB16KKW01-6B-JB Datasheet, NKK Switches Distributor | |
KB16KKW01-6B-JB Details Description
