Linear LT3909IDD#TRPBF
- Mfg. Part Number
- LT3909IDD#TRPBF
- Manufacturer
- Linear
- Product Category
- PMIC - LED Drivers
- Brief Description
- IC LED DRIVER
- Datasheet Download
- LT3909IDD#TRPBF.pdf
Availability of LT3909IDD#TRPBF
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.40001
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LT3909IDD#TRPBF, we specialize in Linear all series electronic components. LT3909IDD#TRPBF can be shipped within 24 hours after order. If you have any demands for LT3909IDD#TRPBF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LT3909IDD#TRPBF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LT3909IDD#TRPBF
| Internal Part Number | EIS-LT3909IDD#TRPBF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Lighting Product Selector | |
| Standard Package | 2,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - LED Drivers | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Type | DC DC Regulator | |
| Topology | Step-Up (Boost) | |
| Internal Switch(s) | Yes | |
| Number of Outputs | 2 | |
| Voltage - Supply (Min) | 2.9V | |
| Voltage - Supply (Max) | 40V | |
| Voltage - Output | 40V | |
| Current - Output / Channel | 50mA | |
| Frequency | 2MHz | |
| Dimming | Analog, PWM | |
| Applications | Automotive | |
| Operating Temperature | -40°C ~ 125°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | 12-WFDFN Exposed Pad | |
| Supplier Device Package | 12-DFN (3x3) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LT3909IDD#TRPBF | |
| Related Links | LT3909I, LT3909IDD#TRPBF Datasheet, Linear Distributor | |
LT3909IDD#TRPBF Details Description
