NKK Switches MB2181SB1W01
- Mfg. Part Number
- MB2181SB1W01
- Manufacturer
- NKK Switches
- Product Category
- Pushbutton Switches
- Brief Description
- SWITCH PUSHBUTTON 4PDT 6A 125V
- Datasheet Download
- MB2181SB1W01.pdf
Availability of MB2181SB1W01
Available Quantity
5029 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 8.06000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MB2181SB1W01, we specialize in NKK Switches all series electronic components. MB2181SB1W01 can be shipped within 24 hours after order. If you have any demands for MB2181SB1W01, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MB2181SB1W01 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MB2181SB1W01
| Internal Part Number | EIS-MB2181SB1W01 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Switch Basics | |
| RoHS Information | Series, Cert of Compliance | |
| Featured Product | Pushbutton Switches | |
| PCN Design/Specification | Multiple Devices O-ring 30/Jun/2011 M Series Toggles, rockers, Pushbuttons CSA Mark Size 23/Jul/2015 | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Pushbutton Switches | |
| Series | MB2000 | |
| Packaging | Bulk | |
| Type | Standard | |
| Circuit | 4PDT | |
| Switch Function | On-Mom | |
| Current Rating | 6A (AC), 3A (DC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 30V | |
| Actuator Type | Plunger for Cap | |
| Color - Actuator/Cap | - | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Panel Mount, Rear | |
| Termination Style | Solder Lug | |
| Ingress Protection | - | |
| Features | Epoxy Sealed Terminals | |
| Panel Cutout Dimensions | Circular - 12.50mm Dia | |
| Operating Temperature | -30°C ~ 85°C | |
| Mechanical Life | 100,000 Cycles | |
| Electrical Life | 25,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MB2181SB1W01 | |
| Related Links | MB2181, MB2181SB1W01 Datasheet, NKK Switches Distributor | |
MB2181SB1W01 Details Description
