NXP Semiconductors/Freescale Semiconductor, Inc. MPC8569CVTAQLJB
- Mfg. Part Number
- MPC8569CVTAQLJB
- Manufacturer
- NXP Semiconductors/Freescale Semiconductor, Inc.
- Product Category
- Embedded - Microprocessors
- Brief Description
- IC MPU MPC85XX 1.067GHZ 783BGA
- Datasheet Download
- MPC8569CVTAQLJB.pdf
Availability of MPC8569CVTAQLJB
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MPC8569CVTAQLJB, we specialize in NXP Semiconductors/Freescale Semiconductor, Inc. all series electronic components. MPC8569CVTAQLJB can be shipped within 24 hours after order. If you have any demands for MPC8569CVTAQLJB, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MPC8569CVTAQLJB Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MPC8569CVTAQLJB
| Internal Part Number | EIS-MPC8569CVTAQLJB | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | ESDHC Host Detect 13/Feb/2012 Errata Update 18/Jun/2014 Errata Update 30/Sep/2014 Errata Update 09/Oct/2014 Errata Update 03/Sep/2015 | |
| PCN Other | MPC8569 Family 27/Sep/2013 | |
| Standard Package | 1 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microprocessors | |
| Series | MPC85xx | |
| Packaging | Tray | |
| Core Processor | PowerPC e500v2 | |
| Number of Cores/Bus Width | 1 Core, 32-Bit | |
| Speed | 1.067GHz | |
| Co-Processors/DSP | Communications; QUICC Engine | |
| RAM Controllers | DDR2, DDR3, SDRAM | |
| Graphics Acceleration | No | |
| Display & Interface Controllers | - | |
| Ethernet | 10/100 Mbps (8), 1 Gbps (4) | |
| SATA | - | |
| USB | USB 2.0 (1) | |
| Voltage - I/O | 1.0V, 1.5V, 1.8V, 2.5V, 3.3V | |
| Operating Temperature | -40°C ~ 105°C | |
| Security Features | - | |
| Package / Case | 783-BBGA, FCBGA | |
| Supplier Device Package | 783-FCPBGA (29x29) | |
| Additional Interfaces | DUART, HSSI, I²C, MMC/SD, PCI, RapidIO, SPI, TDM, UART | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MPC8569CVTAQLJB | |
| Related Links | MPC8569, MPC8569CVTAQLJB Datasheet, NXP Semiconductors/Freescale Semiconductor, Inc. Distributor | |
MPC8569CVTAQLJB Details Description
