Home » All Products » Connectors, Interconnects » Circular Connectors - Housings » MS27474T22B35PCLC

Amphenol Aerospace Operations MS27474T22B35PCLC

MS27474T22B35PCLC picture photo
Mfg. Part Number
MS27474T22B35PCLC
Manufacturer
Product Category
Circular Connectors - Housings
Brief Description
CONN HSG RCPT 100POS JAMNUT PIN
Datasheet Download
MS27474T22B35PCLC.pdf
Availability of MS27474T22B35PCLC

Available Quantity

5020 Pieces

Can ship today

Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks

Marketing Price
$ 64.98000
Our Price
Quote by Email

QUANTITY



EIS Components is the stocking Distributor of MS27474T22B35PCLC, we specialize in Amphenol Aerospace Operations all series electronic components. MS27474T22B35PCLC can be shipped within 24 hours after order. If you have any demands for MS27474T22B35PCLC, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
MS27474T22B35PCLC Order Process
Add Parts to RFQ form
Submit RFQ
We reply within 24 hours
You confirm order
Payment
Ship out your order
Specifications of MS27474T22B35PCLC
Internal Part NumberEIS-MS27474T22B35PCLC
Lead Free Status / RoHS StatusContains lead / RoHS non-compliant
Moisture Sensitivity Level (MSL)1 (Unlimited)
Production Status (Lifecycle)In Production
ConditionNew & Unused, Original Sealed
Standard Package1
Category Connectors, Interconnects
FamilyCircular Connectors - Housings
SeriesMilitary, MIL-DTL-38999 Series II
PackagingBulk
Connector TypeReceptacle for Male Contacts
Number of Positions100
Shell Size - Insert22-35
Shell Size, MIL-
Contact TypeCrimp
Contact Size22D
Mounting TypePanel Mount, Bulkhead - Front Side Nut
Fastening TypeBayonet Lock
OrientationC
Shell Material, FinishAluminum, Olive Drab Cadmium Plated
Ingress ProtectionEnvironment Resistant
Features-
NoteContacts Not Provided
Weight0.001 KG
ApplicationEmail for details
Alternative Part (Replacement)MS27474T22B35PCLC
Related LinksMS27474T, MS27474T22B35PCLC Datasheet, Amphenol Aerospace Operations Distributor
MS27474T22B35PCLC Details Description
