Amphenol Aerospace Operations MS27508E22B21S
- Mfg. Part Number
- MS27508E22B21S
- Manufacturer
- Amphenol Aerospace Operations
- Product Category
- Circular Connectors
- Brief Description
- CONN RCPT 21POS BOX MNT W/SCKT
- Datasheet Download
- MS27508E22B21S.pdf
Availability of MS27508E22B21S
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 82.15720
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MS27508E22B21S, we specialize in Amphenol Aerospace Operations all series electronic components. MS27508E22B21S can be shipped within 24 hours after order. If you have any demands for MS27508E22B21S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MS27508E22B21S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MS27508E22B21S
| Internal Part Number | EIS-MS27508E22B21S | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | MIL-DTL-38999 Series I, II | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors | |
| Series | Military, MIL-DTL-38999 Series II | |
| Packaging | Bulk | |
| Connector Type | Receptacle, Female Sockets | |
| Number of Positions | 21 | |
| Shell Size - Insert | 22-21 | |
| Shell Size, MIL | - | |
| Mounting Type | Panel Mount, Flange | |
| Termination | Crimp | |
| Fastening Type | Bayonet Lock | |
| Orientation | N (Normal) | |
| Ingress Protection | Environment Resistant | |
| Shell Material, Finish | Aluminum, Olive Drab Cadmium Plated | |
| Contact Finish | Gold | |
| Features | - | |
| Contact Finish Thickness | 50µin (1.27µm) | |
| Current Rating | 13A | |
| Voltage - Rated | 900VAC, 1250VDC | |
| Operating Temperature | -65°C ~ 200°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MS27508E22B21S | |
| Related Links | MS27508, MS27508E22B21S Datasheet, Amphenol Aerospace Operations Distributor | |
