TE Connectivity Potter & Brumfield Relays OSA-SS-212DM5,000
- Mfg. Part Number
- OSA-SS-212DM5,000
- Manufacturer
- TE Connectivity Potter & Brumfield Relays
- Product Category
- Power Relays, Over 2 Amps
- Brief Description
- RELAY GEN PURPOSE DPST 5A 12V
- Datasheet Download
- OSA-SS-212DM5,000.pdf
Availability of OSA-SS-212DM5,000
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.12700
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of OSA-SS-212DM5,000, we specialize in TE Connectivity Potter & Brumfield Relays all series electronic components. OSA-SS-212DM5,000 can be shipped within 24 hours after order. If you have any demands for OSA-SS-212DM5,000, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- OSA-SS-212DM5,000 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
OSA-SS-212DM5,000
| Internal Part Number | EIS-OSA-SS-212DM5,000 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1,000 | |
| Category | Relays | |
| Family | Power Relays, Over 2 Amps | |
| Series | OSA, OEG | |
| Packaging | Tray | |
| Relay Type | General Purpose | |
| Coil Type | Non Latching | |
| Coil Current | 45mA | |
| Coil Voltage | 12VDC | |
| Contact Form | DPST (2 Form A) | |
| Contact Rating (Current) | 5A | |
| Switching Voltage | 240VAC, 30VDC - Max | |
| Turn On Voltage (Max) | 9 VDC | |
| Turn Off Voltage (Min) | 0.6 VDC | |
| Operate Time | 20ms | |
| Release Time | 10ms | |
| Features | Sealed - Flux Protection | |
| Mounting Type | Through Hole | |
| Termination Style | PC Pin | |
| Contact Material | Silver Tin Oxide (AgSnO) | |
| Coil Power | 540 mW | |
| Coil Resistance | 270 Ohms | |
| Operating Temperature | -30°C ~ 60°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | OSA-SS-212DM5,000 | |
| Related Links | OSA-SS-2, OSA-SS-212DM5,000 Datasheet, TE Connectivity Potter & Brumfield Relays Distributor | |
OSA-SS-212DM5,000 Details Description
