CUI Inc. PDM1-S24-D9-S
- Mfg. Part Number
- PDM1-S24-D9-S
- Manufacturer
- CUI Inc.
- Product Category
- DC DC Converters
- Brief Description
- CONV DC/DC 1W +/-9V 56MA OUT
- Datasheet Download
- PDM1-S24-D9-S.pdf
Availability of PDM1-S24-D9-S
Available Quantity
5052 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.59800
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PDM1-S24-D9-S, we specialize in CUI Inc. all series electronic components. PDM1-S24-D9-S can be shipped within 24 hours after order. If you have any demands for PDM1-S24-D9-S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PDM1-S24-D9-S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PDM1-S24-D9-S
| Internal Part Number | EIS-PDM1-S24-D9-S | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Low Power DC-DC Converters EMI Regulations and Mitigation Considerations for Switching Power Supplies Reliability Considerations for Power Supplies Power Supply Safety Standards, Agencies and Marks Thermal Management of Power Supplies | |
| RoHS Information | PDM1-S Series Cert of Compliance | |
| 3D Model | PDM1-S24-D9-S | |
| Standard Package | 25 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | PDM1-S | |
| Packaging | Tube | |
| Type | Isolated Module | |
| Number of Outputs | 2 | |
| Voltage - Input (Min) | 21.6V | |
| Voltage - Input (Max) | 26.4V | |
| Voltage - Output 1 | 9V | |
| Voltage - Output 2 | -9V | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 56mA, 56mA | |
| Power (Watts) - Manufacture Series | 1W | |
| Voltage - Isolation | 1.5kV (1500V) | |
| Features | SCP | |
| Mounting Type | Through Hole | |
| Package / Case | 6-DIP Module (5 Leads) | |
| Size / Dimension | 0.77" L x 0.24" W x 0.37" H (19.5mm x 6.0mm x 9.3mm) | |
| Operating Temperature | -40°C ~ 105°C | |
| Efficiency | 80% | |
| Power (Watts) - Max | 1W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PDM1-S24-D9-S | |
| Related Links | PDM1-S, PDM1-S24-D9-S Datasheet, CUI Inc. Distributor | |
