Diodes Incorporated SBRT30A45CT
- Mfg. Part Number
- SBRT30A45CT
- Manufacturer
- Diodes Incorporated
- Product Category
- Diodes, Rectifiers - Arrays
- Brief Description
- DIODE SBR ARRAY 45V 15A ITO220AB
- Datasheet Download
- SBRT30A45CT.pdf
Availability of SBRT30A45CT
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.57000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SBRT30A45CT, we specialize in Diodes Incorporated all series electronic components. SBRT30A45CT can be shipped within 24 hours after order. If you have any demands for SBRT30A45CT, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SBRT30A45CT Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SBRT30A45CT
| Internal Part Number | EIS-SBRT30A45CT | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 50 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes, Rectifiers - Arrays | |
| Series | TrenchSBR | |
| Packaging | Tube | |
| Diode Configuration | 1 Pair Common Cathode | |
| Diode Type | Super Barrier | |
| Voltage - DC Reverse (Vr) (Max) | 45V | |
| Current - Average Rectified (Io) (per Diode) | 15A | |
| Voltage - Forward (Vf) (Max) @ If | 510mV @ 15A | |
| Speed | Standard Recovery >500ns, > 200mA (Io) | |
| Reverse Recovery Time (trr) | - | |
| Current - Reverse Leakage @ Vr | 400µA @ 45V | |
| Mounting Type | Through Hole | |
| Package / Case | TO-220-3 | |
| Supplier Device Package | TO-220AB | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SBRT30A45CT | |
| Related Links | SBRT3, SBRT30A45CT Datasheet, Diodes Incorporated Distributor | |
SBRT30A45CT Details Description
