Amphenol Pcd SCM073000
- Mfg. Part Number
- SCM073000
- Manufacturer
- Amphenol Pcd
- Product Category
- Terminal Blocks - Wire to Board
- Brief Description
- CONN TERM BLK 7POS 5.08MM ANGLED
- Datasheet Download
- SCM073000.pdf
Availability of SCM073000
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 4.12200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SCM073000, we specialize in Amphenol Pcd all series electronic components. SCM073000 can be shipped within 24 hours after order. If you have any demands for SCM073000, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SCM073000 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SCM073000
| Internal Part Number | EIS-SCM073000 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 25 | |
| Category | Connectors, Interconnects | |
| Family | Terminal Blocks - Wire to Board | |
| Series | SCM | |
| Packaging | Tray | |
| Number of Levels | 1 | |
| Positions Per Level | 7 | |
| Pitch | 0.200" (5.08mm) | |
| Mating Orientation | Angled | |
| Current | 20A | |
| Voltage | 300V | |
| Wire Gauge | 12-28 AWG | |
| Mounting Type | Through Hole | |
| Wire Termination | Screwless - Spring Cage, Tension Clamp | |
| Features | Interlocking (Side) | |
| Color | Black | |
| Operating Temperature | 125°C | |
| Housing Material | Polyamide (PA), Nylon | |
| Contact Material - Plating | Brass - Tin Plated | |
| Clamp Material - Plating | Steel, Stainless | |
| Screw Material - Plating | - | |
| Torque - Screw | - | |
| Screw Thread | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SCM073000 | |
| Related Links | SCM0, SCM073000 Datasheet, Amphenol Pcd Distributor | |
