FFF SFV26R-4STBE1HLF
- Mfg. Part Number
- SFV26R-4STBE1HLF
- Manufacturer
- FFF
- Product Category
- FFC, FPC (Flat Flexible) Connectors
- Brief Description
- CONN FPC TOP 26POS 0.50MM R/A
- Datasheet Download
- SFV26R-4STBE1HLF.pdf
Availability of SFV26R-4STBE1HLF
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.25071
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SFV26R-4STBE1HLF, we specialize in FFF all series electronic components. SFV26R-4STBE1HLF can be shipped within 24 hours after order. If you have any demands for SFV26R-4STBE1HLF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SFV26R-4STBE1HLF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SFV26R-4STBE1HLF
| Internal Part Number | EIS-SFV26R-4STBE1HLF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 6,000 | |
| Category | Connectors, Interconnects | |
| Family | FFC, FPC (Flat Flexible) Connectors | |
| Series | SFV-R | |
| Packaging | Tape & Reel (TR) | |
| Flat Flex Type | FPC | |
| Mounting Type | Surface Mount, Right Angle | |
| Connector/Contact Type | Contacts, Top | |
| Number of Positions | 26 | |
| Pitch | 0.020" (0.50mm) | |
| Termination | Solder | |
| FFC, FCB Thickness | 0.33mm | |
| Height Above Board | 0.071" (1.80mm) | |
| Locking Feature | Slide Lock | |
| Cable End Type | Notched | |
| Contact Material | Phosphor Bronze | |
| Contact Finish | Gold | |
| Housing Material | Liquid Crystal Polymer (LCP), Glass Filled, Halogen Free | |
| Actuator Material | Polyphenylene Sulfide (PPS), Glass Filled, Halogen Free | |
| Features | Solder Retention, Zero Insertion Force (ZIF) | |
| Voltage Rating | 50V | |
| Operating Temperature | -55°C ~ 105°C | |
| Material Flammability Rating | UL94 V-0 | |
| Current Rating | 0.5A | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SFV26R-4STBE1HLF | |
| Related Links | SFV26R-4, SFV26R-4STBE1HLF Datasheet, FFF Distributor | |
SFV26R-4STBE1HLF Details Description
