FFF SFW6R-6STE1
- Mfg. Part Number
- SFW6R-6STE1
- Manufacturer
- FFF
- Product Category
- FFC, FPC (Flat Flexible) Connectors
- Brief Description
- CONN CIC TOP 6POS 1.00MM R/A
- Datasheet Download
- SFW6R-6STE1.pdf
Availability of SFW6R-6STE1
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SFW6R-6STE1, we specialize in FFF all series electronic components. SFW6R-6STE1 can be shipped within 24 hours after order. If you have any demands for SFW6R-6STE1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SFW6R-6STE1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SFW6R-6STE1
| Internal Part Number | EIS-SFW6R-6STE1 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | FFC/FPC NON-LF 09/May/2012 | |
| Standard Package | 4,000 | |
| Category | Connectors, Interconnects | |
| Family | FFC, FPC (Flat Flexible) Connectors | |
| Series | SFW-R | |
| Packaging | Tape & Reel (TR) | |
| Flat Flex Type | CIC | |
| Mounting Type | Surface Mount, Right Angle | |
| Connector/Contact Type | Contacts, Top | |
| Number of Positions | 6 | |
| Pitch | 0.039" (1.00mm) | |
| Termination | Solder | |
| FFC, FCB Thickness | 0.30mm | |
| Height Above Board | 0.106" (2.70mm) | |
| Locking Feature | Slide Lock | |
| Cable End Type | Tapered | |
| Contact Material | - | |
| Contact Finish | - | |
| Housing Material | Polyphenylene Sulfide (PPS), Glass Filled | |
| Actuator Material | - | |
| Features | Zero Insertion Force (ZIF) | |
| Voltage Rating | - | |
| Operating Temperature | - | |
| Material Flammability Rating | - | |
| Current Rating | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SFW6R-6STE1 | |
| Related Links | SFW6R, SFW6R-6STE1 Datasheet, FFF Distributor | |
SFW6R-6STE1 Details Description
