SiTIME SIT9003AC-8-28SD
- Mfg. Part Number
- SIT9003AC-8-28SD
- Manufacturer
- SiTIME
- Product Category
- Programmable Oscillators
- Brief Description
- OSC MEMS PROG 7.0X5.0MM 2.8V
- Datasheet Download
- SIT9003AC-8-28SD.pdf
Availability of SIT9003AC-8-28SD
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.07100
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SIT9003AC-8-28SD, we specialize in SiTIME all series electronic components. SIT9003AC-8-28SD can be shipped within 24 hours after order. If you have any demands for SIT9003AC-8-28SD, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SIT9003AC-8-28SD Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SIT9003AC-8-28SD
| Internal Part Number | EIS-SIT9003AC-8-28SD | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Crystals and Oscillators | |
| Family | Programmable Oscillators | |
| Series | SiT9003 | |
| Packaging | Bulk | |
| Type | Programmed by Digi-Key (Enter your frequency in Web Order Notes) | |
| Available Frequency Range | 1MHz ~ 110MHz | |
| Function | Standby | |
| Output | LVCMOS, LVTTL | |
| Voltage - Supply | 2.8V | |
| Frequency Stability | ±50ppm | |
| Operating Temperature | -20°C ~ 70°C | |
| Spread Spectrum Bandwidth | ±0.50%, Center Spread | |
| Current - Supply (Max) | 4.1mA | |
| Mounting Type | Surface Mount | |
| Package / Case | 4-SMD, No Lead (DFN, LCC) | |
| Height | 0.039" (1.00mm) | |
| Size / Dimension | 0.276" L x 0.197" W (7.00mm x 5.00mm) | |
| Current - Supply (Disable) (Max) | 2.2µA | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SIT9003AC-8-28SD | |
| Related Links | SIT9003A, SIT9003AC-8-28SD Datasheet, SiTIME Distributor | |
