Luminus Devices Inc. SSR-90-R-R11-HJ101
- Mfg. Part Number
- SSR-90-R-R11-HJ101
- Manufacturer
- Luminus Devices Inc.
- Product Category
- LED Lighting - COBs, Engines, Modules
- Brief Description
- BIG CHIP LED HB MODULE RED
- Datasheet Download
- SSR-90-R-R11-HJ101.pdf
Availability of SSR-90-R-R11-HJ101
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SSR-90-R-R11-HJ101, we specialize in Luminus Devices Inc. all series electronic components. SSR-90-R-R11-HJ101 can be shipped within 24 hours after order. If you have any demands for SSR-90-R-R11-HJ101, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SSR-90-R-R11-HJ101 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SSR-90-R-R11-HJ101
| Internal Part Number | EIS-SSR-90-R-R11-HJ101 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Lighting Product Selector | |
| Standard Package | 25 | |
| Category | Optoelectronics | |
| Family | LED Lighting - COBs, Engines, Modules | |
| Series | SSR-90 | |
| Packaging | Tape & Reel (TR) | |
| Type | LED Module | |
| Color | Red | |
| CCT (K) | - | |
| Wavelength | 624nm | |
| Configuration | Starboard | |
| Flux @ Current/Temperature - Test | - | |
| Current - Test | 3.15A | |
| Temperature - Test | - | |
| Voltage - Forward (Vf) (Typ) | 2V | |
| Lumens/Watt @ Current - Test | - | |
| Current - Max | 27A | |
| CRI (Color Rendering Index) | - | |
| Viewing Angle | 100° | |
| Features | - | |
| Size / Dimension | 19.90mm L x 19.90mm W | |
| Height | 7.10mm | |
| Light Emitting Surface (LES) | 8.00mm Diameter | |
| Lens Type | Domed | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SSR-90-R-R11-HJ101 | |
| Related Links | SSR-90-R-, SSR-90-R-R11-HJ101 Datasheet, Luminus Devices Inc. Distributor | |
