ST STM32F100V8T7B
- Mfg. Part Number
- STM32F100V8T7B
- Manufacturer
- ST
- Product Category
- Embedded - Microcontrollers
- Brief Description
- MCU 32BIT 64K FLASH 100LQFP
- Datasheet Download
- STM32F100V8T7B.pdf
Availability of STM32F100V8T7B
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.07431
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of STM32F100V8T7B, we specialize in ST all series electronic components. STM32F100V8T7B can be shipped within 24 hours after order. If you have any demands for STM32F100V8T7B, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- STM32F100V8T7B Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
STM32F100V8T7B
| Internal Part Number | EIS-STM32F100V8T7B | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | STM32F100V8 View All Specifications | |
| Product Training Modules | Smart Grid Solutions: Smart Grid Distribution/Smart Meters STM32Cube | |
| Design Resources | Development Tool Selector | |
| Featured Product | STM32 32-bit Cortex MCUs | |
| Standard Package | 90 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | STM32 F1 | |
| Packaging | Tray | |
| Core Processor | ARM® Cortex®-M3 | |
| Core Size | 32-Bit | |
| Speed | 24MHz | |
| Connectivity | I²C, IrDA, LIN, SPI, UART/USART | |
| Peripherals | DMA, PDR, POR, PVD, PWM, Temp Sensor, WDT | |
| Number of I/O | 80 | |
| Program Memory Size | 64KB (64K x 8) | |
| Program Memory Type | FLASH | |
| EEPROM Size | - | |
| RAM Size | 8K x 8 | |
| Voltage - Supply (Vcc/Vdd) | 2 V ~ 3.6 V | |
| Data Converters | A/D 16x12b; D/A 2x12b | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 105°C | |
| Package / Case | 100-LQFP | |
| Supplier Device Package | 100-LQFP (14x14) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | STM32F100V8T7B | |
| Related Links | STM32F1, STM32F100V8T7B Datasheet, ST Distributor | |
STM32F100V8T7B Details Description
