Microchip Technology TC1410NEOA
- Mfg. Part Number
- TC1410NEOA
- Manufacturer
- Microchip Technology
- Product Category
- PMIC - Gate Drivers
- Brief Description
- IC MOSFET DVR .5A HS 8SOIC
- Datasheet Download
- TC1410NEOA.pdf
Availability of TC1410NEOA
Available Quantity
6781 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.86000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TC1410NEOA, we specialize in Microchip Technology all series electronic components. TC1410NEOA can be shipped within 24 hours after order. If you have any demands for TC1410NEOA, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TC1410NEOA Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TC1410NEOA
| Internal Part Number | EIS-TC1410NEOA | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | SOIC-8L Copper Bond Wire 18/Dec/2013 Die Attach Epoxy Update 21/Sep/2015 | |
| PCN Assembly/Origin | SOIC-8L Copper Bond Wire Revision 06/Feb/2014 Assembly Site Addition 08/Apr/2015 Assembly Site Addition 08/Apr/2015 | |
| PCN Packaging | Label and Packing Changes 23/Sep/2015 | |
| Standard Package | 100 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Gate Drivers | |
| Series | - | |
| Packaging | Tube | |
| Configuration | Low-Side | |
| Input Type | Non-Inverting | |
| Delay Time | 30ns | |
| Current - Peak | 500mA | |
| Number of Configurations | 1 | |
| Number of Outputs | 1 | |
| High Side Voltage - Max (Bootstrap) | - | |
| Voltage - Supply | 4.5 V ~ 16 V | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 8-SOIC N | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TC1410NEOA | |
| Related Links | TC141, TC1410NEOA Datasheet, Microchip Technology Distributor | |
