Panasonic Electric Works TXS2SS-6V-X
- Mfg. Part Number
- TXS2SS-6V-X
- Manufacturer
- Panasonic Electric Works
- Product Category
- Signal Relays, Up to 2 Amps
- Brief Description
- RELAY GENERAL PURPOSE DPDT 1A 6V
- Datasheet Download
- TXS2SS-6V-X.pdf
Availability of TXS2SS-6V-X
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.74500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TXS2SS-6V-X, we specialize in Panasonic Electric Works all series electronic components. TXS2SS-6V-X can be shipped within 24 hours after order. If you have any demands for TXS2SS-6V-X, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TXS2SS-6V-X Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TXS2SS-6V-X
| Internal Part Number | EIS-TXS2SS-6V-X | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 4 (72 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | Relay Technical Info Standards Chart | |
| Standard Package | 500 | |
| Category | Relays | |
| Family | Signal Relays, Up to 2 Amps | |
| Series | TX-S | |
| Packaging | Tape & Reel (TR) | |
| Relay Type | General Purpose | |
| Coil Type | Non Latching | |
| Coil Current | 8.3mA | |
| Coil Voltage | 6VDC | |
| Contact Form | DPDT (2 Form C) | |
| Contact Rating (Current) | 1A | |
| Switching Voltage | 110VDC - Max | |
| Turn On Voltage (Max) | 4.8 VDC | |
| Turn Off Voltage (Min) | 0.6 VDC | |
| Operate Time | 5ms | |
| Release Time | 5ms | |
| Features | Sealed - Fully | |
| Mounting Type | Surface Mount | |
| Termination Style | Gull Wing | |
| Contact Material | Silver (Ag), Gold (Au) | |
| Coil Power | 50 mW | |
| Coil Resistance | 720 Ohms | |
| Operating Temperature | -40°C ~ 70°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TXS2SS-6V-X | |
| Related Links | TXS2S, TXS2SS-6V-X Datasheet, Panasonic Electric Works Distributor | |
