ST VNH5180ATR-E
- Mfg. Part Number
- VNH5180ATR-E
- Manufacturer
- ST
- Product Category
- PMIC - Motor Drivers, Controllers
- Brief Description
- IC MOTOR DRIVER PAR 36POWERSSO
- Datasheet Download
- VNH5180ATR-E.pdf
Availability of VNH5180ATR-E
Available Quantity
6020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.59600
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of VNH5180ATR-E, we specialize in ST all series electronic components. VNH5180ATR-E can be shipped within 24 hours after order. If you have any demands for VNH5180ATR-E, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- VNH5180ATR-E Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
VNH5180ATR-E
| Internal Part Number | EIS-VNH5180ATR-E | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | VNH5180A-E View All Specifications | |
| Product Training Modules | VIPower H-Bridges L99ASC03 Fully-Integrated Motor Driver IC for Three-Phase Brushless Motors | |
| Standard Package | 1,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Motor Drivers, Controllers | |
| Series | ECOPACK®, VIPower™ | |
| Motor Type - Stepper | - | |
| Motor Type - AC, DC | Brushed DC | |
| Function | Driver - Fully Integrated, Control and Power Stage | |
| Output Configuration | Half Bridge (2) | |
| Interface | Parallel, PWM | |
| Technology | Power MOSFET | |
| Step Resolution | - | |
| Applications | Automotive | |
| Current - Output | 8A | |
| Voltage - Supply | 5.5 V ~ 18 V | |
| Voltage - Load | 5.5 V ~ 18 V | |
| Operating Temperature | -40°C ~ 150°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | 36-BFSOP (0.295", 7.50mm Width) Exposed Pad | |
| Supplier Device Package | PowerSSO-36 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | VNH5180ATR-E | |
| Related Links | VNH518, VNH5180ATR-E Datasheet, ST Distributor | |
