Atmel ATSAMD20J15A-CUT
- Mfg. Part Number
- ATSAMD20J15A-CUT
- Manufacturer
- Atmel
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC MCU 32BIT 32KB FLASH 64UFBGA
- Datasheet Download
- ATSAMD20J15A-CUT.pdf
Availability of ATSAMD20J15A-CUT
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.67750
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ATSAMD20J15A-CUT, we specialize in Atmel all series electronic components. ATSAMD20J15A-CUT can be shipped within 24 hours after order. If you have any demands for ATSAMD20J15A-CUT, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ATSAMD20J15A-CUT Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ATSAMD20J15A-CUT
| Internal Part Number | EIS-ATSAMD20J15A-CUT | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Video File | Introducing Atmel Studio 7 | |
| Design Resources | Development Tool Selector | |
| PCN Design/Specification | ATSAMD20 Errata Update 20/Jan/2015 | |
| PCN Packaging | Tape and Reel Label Update 10/Feb/2015 | |
| Standard Package | 6,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | SAM D20J | |
| Packaging | Tape & Reel (TR) | |
| Core Processor | ARM® Cortex®-M0+ | |
| Core Size | 32-Bit | |
| Speed | 48MHz | |
| Connectivity | I²C, SPI, UART/USART | |
| Peripherals | Brown-out Detect/Reset, POR, WDT | |
| Number of I/O | 52 | |
| Program Memory Size | 32KB (32K x 8) | |
| Program Memory Type | FLASH | |
| EEPROM Size | - | |
| RAM Size | 4K x 8 | |
| Voltage - Supply (Vcc/Vdd) | 1.62 V ~ 3.6 V | |
| Data Converters | A/D 20x12b, D/A 1x10b | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 64-UFBGA | |
| Supplier Device Package | 64-UFBGA (5x5) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ATSAMD20J15A-CUT | |
| Related Links | ATSAMD20, ATSAMD20J15A-CUT Datasheet, Atmel Distributor | |
ATSAMD20J15A-CUT Details Description
