Avago Technologies US, Inc. HCPL-0314#500
- Mfg. Part Number
- HCPL-0314#500
- Manufacturer
- Avago Technologies US, Inc.
- Product Category
- Isolators - Gate Drivers
- Brief Description
- OPTOISO 3.75KV GATE DRIVER 8SO
- Datasheet Download
- HCPL-0314#500.pdf
Availability of HCPL-0314#500
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.41645
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of HCPL-0314#500, we specialize in Avago Technologies US, Inc. all series electronic components. HCPL-0314#500 can be shipped within 24 hours after order. If you have any demands for HCPL-0314#500, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- HCPL-0314#500 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
HCPL-0314#500
| Internal Part Number | EIS-HCPL-0314#500 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | Mult Device Design Changes 10/Nov/2015 | |
| PCN Packaging | Multiple Devices Marking/Labeling 07/Aug/2013 Marking/Labeling Revision B 14/Jan/2014 | |
| Standard Package | 1,500 | |
| Category | Isolators | |
| Family | Isolators - Gate Drivers | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Technology | Optical Coupling | |
| Number of Channels | 1 | |
| Voltage - Isolation | 3750Vrms | |
| Common Mode Transient Immunity (Min) | 25kV/µs | |
| Propagation Delay tpLH / tpHL (Max) | 700ns, 700ns | |
| Pulse Width Distortion (Max) | - | |
| Rise / Fall Time (Typ) | 50ns, 50ns | |
| Current - Output High, Low | 400mA, 400mA | |
| Current - Peak Output | 600mA | |
| Voltage - Forward (Vf) (Typ) | 1.5V | |
| Current - DC Forward (If) (Max) | 25mA | |
| Voltage - Supply | 10 V ~ 30 V | |
| Operating Temperature | -40°C ~ 100°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 8-SO | |
| Approvals | CSA, UR | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | HCPL-0314#500 | |
| Related Links | HCPL-0, HCPL-0314#500 Datasheet, Avago Technologies US, Inc. Distributor | |
