Texas Instruments LMV824DGVRG4
- Mfg. Part Number
- LMV824DGVRG4
- Manufacturer
- Texas Instruments
- Product Category
- Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
- Brief Description
- IC OPAMP GP 5.5MHZ RRO 14TVSOP
- Datasheet Download
- LMV824DGVRG4.pdf
Availability of LMV824DGVRG4
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LMV824DGVRG4, we specialize in Texas Instruments all series electronic components. LMV824DGVRG4 can be shipped within 24 hours after order. If you have any demands for LMV824DGVRG4, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LMV824DGVRG4 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LMV824DGVRG4
| Internal Part Number | EIS-LMV824DGVRG4 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | Create your power design now with TI’s WEBENCH® Designer | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 2,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Amplifier Type | General Purpose | |
| Number of Circuits | 4 | |
| Output Type | Rail-to-Rail | |
| Slew Rate | 1.9 V/µs | |
| Gain Bandwidth Product | 5.5MHz | |
| -3db Bandwidth | - | |
| Current - Input Bias | 40nA | |
| Voltage - Input Offset | 1mV | |
| Current - Supply | 1mA | |
| Current - Output / Channel | 45mA | |
| Voltage - Supply, Single/Dual (±) | 2.5 V ~ 5.5 V, ±1.25 V ~ 2.75 V | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 14-TFSOP (0.173", 4.40mm Width) | |
| Supplier Device Package | 14-TVSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LMV824DGVRG4 | |
| Related Links | LMV824, LMV824DGVRG4 Datasheet, Texas Instruments Distributor | |
LMV824DGVRG4 Details Description
