Microsemi Commercial Components MPLAD30KP20CAE3
- Mfg. Part Number
- MPLAD30KP20CAE3
- Manufacturer
- Microsemi Commercial Components
- Product Category
- TVS - Diodes
- Brief Description
- TVS DIODE 20VWM 34VC PLAD
- Datasheet Download
- MPLAD30KP20CAE3.pdf
Availability of MPLAD30KP20CAE3
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 39.70500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MPLAD30KP20CAE3, we specialize in Microsemi Commercial Components all series electronic components. MPLAD30KP20CAE3 can be shipped within 24 hours after order. If you have any demands for MPLAD30KP20CAE3, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MPLAD30KP20CAE3 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MPLAD30KP20CAE3
| Internal Part Number | EIS-MPLAD30KP20CAE3 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 1 | |
| Category | Circuit Protection | |
| Family | TVS - Diodes | |
| Series | - | |
| Packaging | Bulk | |
| Type | Zener | |
| Unidirectional Channels | - | |
| Bidirectional Channels | 1 | |
| Voltage - Reverse Standoff (Typ) | 20V | |
| Voltage - Breakdown (Min) | 22.2V | |
| Voltage - Clamping (Max) @ Ipp | 34V | |
| Current - Peak Pulse (10/1000µs) | 882A | |
| Power - Peak Pulse | 30000W (30kW) | |
| Power Line Protection | No | |
| Applications | General Purpose | |
| Capacitance @ Frequency | - | |
| Operating Temperature | -55°C ~ 150°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | Nonstandard SMD | |
| Supplier Device Package | PLAD | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MPLAD30KP20CAE3 | |
| Related Links | MPLAD30, MPLAD30KP20CAE3 Datasheet, Microsemi Commercial Components Distributor | |
