Vishay/Dale RCL06121M00JNEA
- Mfg. Part Number
- RCL06121M00JNEA
- Manufacturer
- Vishay/Dale
- Product Category
- Chip Resistor - Surface Mount
- Brief Description
- RES SMD 1M OHM 1/2W 1206 WIDE
- Datasheet Download
- RCL06121M00JNEA.pdf
Availability of RCL06121M00JNEA
Available Quantity
10020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.03022
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of RCL06121M00JNEA, we specialize in Vishay/Dale all series electronic components. RCL06121M00JNEA can be shipped within 24 hours after order. If you have any demands for RCL06121M00JNEA, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- RCL06121M00JNEA Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
RCL06121M00JNEA
| Internal Part Number | EIS-RCL06121M00JNEA | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 5,000 | |
| Category | Resistors | |
| Family | Chip Resistor - Surface Mount | |
| Series | RCL | |
| Packaging | Tape & Reel (TR) | |
| Resistance (Ohms) | 1M | |
| Tolerance | ±5% | |
| Power (Watts) | 0.5W, 1/2W | |
| Composition | Thick Film | |
| Features | Automotive AEC-Q200 | |
| Temperature Coefficient | ±200ppm/°C | |
| Operating Temperature | -55°C ~ 155°C | |
| Package / Case | Wide 1206 (3216 Metric), 0612 | |
| Supplier Device Package | 0612 (1632 Metric) | |
| Size / Dimension | 0.063" L x 0.126" W (1.60mm x 3.20mm) | |
| Height | 0.026" (0.65mm) | |
| Number of Terminations | 2 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | RCL06121M00JNEA | |
| Related Links | RCL0612, RCL06121M00JNEA Datasheet, Vishay/Dale Distributor | |
RCL06121M00JNEA Details Description
