Ohmite RW3R0DB5R00JE
- Mfg. Part Number
- RW3R0DB5R00JE
- Manufacturer
- Ohmite
- Product Category
- Chip Resistor - Surface Mount
- Brief Description
- RES SMD 5 OHM 5% 3W J LEAD
- Datasheet Download
- RW3R0DB5R00JE.pdf
Availability of RW3R0DB5R00JE
Available Quantity
5287 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.00400
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of RW3R0DB5R00JE, we specialize in Ohmite all series electronic components. RW3R0DB5R00JE can be shipped within 24 hours after order. If you have any demands for RW3R0DB5R00JE, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- RW3R0DB5R00JE Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
RW3R0DB5R00JE
| Internal Part Number | EIS-RW3R0DB5R00JE | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Current Sensing Resistors | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 100 | |
| Category | Resistors | |
| Family | Chip Resistor - Surface Mount | |
| Series | RW | |
| Packaging | Bulk | |
| Resistance (Ohms) | 5 | |
| Tolerance | ±5% | |
| Power (Watts) | 3W | |
| Composition | Wirewound | |
| Features | Current Sense | |
| Temperature Coefficient | ±50ppm/°C | |
| Operating Temperature | -55°C ~ 150°C | |
| Package / Case | 6327 J-Lead | |
| Supplier Device Package | SMD J-Lead, Recessed | |
| Size / Dimension | 0.625" L x 0.273" W (15.88mm x 6.93mm) | |
| Height | 0.231" (5.87mm) | |
| Number of Terminations | 2 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | RW3R0DB5R00JE | |
| Related Links | RW3R0D, RW3R0DB5R00JE Datasheet, Ohmite Distributor | |
RW3R0DB5R00JE Details Description
