ST ST72F324BK4T6
- Mfg. Part Number
- ST72F324BK4T6
- Manufacturer
- ST
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC MCU 8BIT 16K FLASH 32-LQFP
- Datasheet Download
- ST72F324BK4T6.pdf
Availability of ST72F324BK4T6
Available Quantity
5045 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.39680
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ST72F324BK4T6, we specialize in ST all series electronic components. ST72F324BK4T6 can be shipped within 24 hours after order. If you have any demands for ST72F324BK4T6, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ST72F324BK4T6 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ST72F324BK4T6
| Internal Part Number | EIS-ST72F324BK4T6 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | ST72324BK4 View All Specifications | |
| Design Resources | Development Tool Selector | |
| Featured Product | Flasher Series of Production Tools | |
| Standard Package | 250 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | ST7 | |
| Packaging | Tray | |
| Core Processor | ST7 | |
| Core Size | 8-Bit | |
| Speed | 8MHz | |
| Connectivity | SCI, SPI | |
| Peripherals | LVD, POR, PWM, WDT | |
| Number of I/O | 24 | |
| Program Memory Size | 16KB (16K x 8) | |
| Program Memory Type | FLASH | |
| EEPROM Size | - | |
| RAM Size | 512 x 8 | |
| Voltage - Supply (Vcc/Vdd) | 3.8 V ~ 5.5 V | |
| Data Converters | A/D 12x10b | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 32-LQFP | |
| Supplier Device Package | * | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ST72F324BK4T6 | |
| Related Links | ST72F3, ST72F324BK4T6 Datasheet, ST Distributor | |
ST72F324BK4T6 Details Description
