Omron XM3B-1522-132
- Mfg. Part Number
- XM3B-1522-132
- Manufacturer
- Omron
- Product Category
- D-Sub Connectors
- Brief Description
- D-Sub Connector Receptacle, Female Sockets 15 Position Through Hole, Right Angle Solder
- Datasheet Download
- XM3B-1522-132.pdf
Availability of XM3B-1522-132
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 5.48657
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of XM3B-1522-132, we specialize in Omron all series electronic components. XM3B-1522-132 can be shipped within 24 hours after order. If you have any demands for XM3B-1522-132, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- XM3B-1522-132 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
XM3B-1522-132
| Internal Part Number | EIS-XM3B-1522-132 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 70 | |
| Category | Connectors, Interconnects | |
| Family | D-Sub Connectors | |
| Series | XM3B | |
| Packaging | Tape & Reel (TR) | |
| Connector Style | D-Sub | |
| Connector Type | Receptacle, Female Sockets | |
| Number of Positions | 15 | |
| Number of Rows | 2 | |
| Shell Size, Connector Layout | 2 (DA, A) | |
| Contact Type | Signal | |
| Mounting Type | Through Hole, Right Angle | |
| Flange Feature | Mating Side; Female Screwlock (4-40) | |
| Termination | Solder | |
| Features | Board Lock, Shielded | |
| Shell Material, Finish | Steel, Nickel Plated | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 16µin (0.40µm) | |
| Ingress Protection | - | |
| Operating Temperature | -55°C ~ 105°C | |
| Voltage Rating | 300V | |
| Current Rating | 5A | |
| Housing Material | Polybutylene Terephthalate (PBT), Glass Filled | |
| Color | Black | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | XM3B-1522-132 | |
| Related Links | XM3B-1, XM3B-1522-132 Datasheet, Omron Distributor | |
XM3B-1522-132 Details Description
